109-1003-006 Char-Lynn 4000 Series Hydraulic Motor 4 Bolt Disc Geroler Motor

Shijiazhuang Hanjiu Technology Co.,Ltd
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

109-1003-006 Char-Lynn 4000 Series Hydraulic Motor 4 Bolt Disc Geroler Motor

Brand Name : HANJIU

Model Number : 4000 series

Certification : ISO 2015:9001

Place of Origin : CHINA

MOQ : 1 Sets

Price : Start from 500 usd

Payment Terms : L/C, T/T, Western Union, Western Union

Supply Ability : 300000 sets per year

Delivery Time : 15 - 45 work days

Packaging Details : Carton, Box, Pallets

Item : Disc Geroler motors

material : cast iron

Direction of rotation : Reversible

Fastening : 4 Bolts standard type

Maximum pressure : 3500 bar

charlynn code : 109-1003

Contact Now

109-1003-006 Char-Lynn 4000 Series Hydraulic Motor 4 bolt Disc geroler motor

Product details:

Disc Motor
Geroler
Disc Valve109-1003-006 Char-Lynn 4000 Series Hydraulic Motor

1-1/4 cylindrical shaft
Standard SAE B mount
3/4'' Split Flange Ports
205cc displacement

Main Specifications:

TYPE BMK4 BMK4 BMK4 BMK4 BMK4 BMK4
160 200 250 315 400 500
Displacement(ml/r) 159.2 195.6 246.1 311.6 391.3 490.8
Max.speed(rpm) cont. 560 440 300 234 188 155
int. 670 535 450 351 282 232
Max.Pressure.Drop(Mpa) cont. 20 20 20 20 20 20
int. 30 30 30 30 30 27.5
peak. 30 30 30 30 30 30
Max.Torque(N.m) cont. 450 565 710 920 1160 1445
int. 680 855 1080 1325 1625 1880
Max.Flow(cont.)(L/min) cont. 95 95 150 150 150 150
int. 115 115 205 225 225 225
Weight(kg) 26.3 26.5 26.8 27.3 28 28.8

109-1003-006 Char-Lynn 4000 Series Hydraulic Motor 4 Bolt Disc Geroler Motor109-1003-006 Char-Lynn 4000 Series Hydraulic Motor 4 Bolt Disc Geroler Motor109-1003-006 Char-Lynn 4000 Series Hydraulic Motor 4 Bolt Disc Geroler Motor

109-1003-006 Char-Lynn 4000 Series Hydraulic Motor 4 Bolt Disc Geroler Motor

Geroler motors are a type of hydraulic motor known for their high torque output at low speeds. This makes them ideal for various heavy-duty applications where significant rotational force is required. Here are some common applications of Geroler motors

Construction Equipment

Excavators The powerful torque of Geroler motors is essential for digging and lifting heavy loads.

Cranes Geroler motors provide the necessary force for lifting and moving heavy objects.

Drilling rigs The high torque output is ideal for drilling into the ground.

Agricultural Machinery

Tractors Geroler motors power the various implements used in agriculture, such as plows, harrows, and balers.

Harvesters The high torque is required for cutting, threshing, and transporting crops.

Industrial Machinery

Presses Geroler motors provide the force needed for pressing and forming materials.

Conveyors The high torque can be used to move heavy loads along conveyor belts.

Mixers Geroler motors are used to power the mixing blades in various industrial processes.

Marine Applications

Winches Geroler motors are used to power winches for lifting and lowering heavy objects.

Steering systems The high torque can be used to turn the rudders of large ships.

Mobile Equipment

Forklifts Geroler motors provide the power for lifting and moving heavy loads.

Aerial work platforms The high torque is needed to lift the platform to high altitudes.

Other Applications

Oil and gas industry Geroler motors are used in various applications, such as pumping and drilling.

Mining industry The high torque is required for moving heavy equipment and materials.

Manufacturing Geroler motors are used in various manufacturing processes, such as metalworking and plastics processing.

These are just a few examples of the many applications of Geroler motors. Their versatility and high torque output make them a valuable component in a wide range of industries.

Contact a hydraulics specialist or HANJIU . Solve all your hydraulic motor problems

109-1003-006 Char-Lynn 4000 Series Hydraulic Motor 4 Bolt Disc Geroler Motor
