BMPH-315-H4-H-S-B Motor - SAE"A"4-Bolt, 1" Parallel .40 Dia Crosshole, 7/8-14 SAE

  • 1
  • 2
  • 3

Brand Name : HANJIU

Model Number : BMPH-315-H4-H-S-B

Certification : CE

Place of Origin : China

MOQ : 100 Pieces

Price : Contact seller to ask

Payment Terms : L/C, D/A, D/P, T/T, Western Union

Supply Ability : 10000 pieces per year

Delivery Time : 35 work days

Packaging Details : Box, Pallet

Item : Hydraulic Motor

Direction : Left and right

OEM # : BMPH-315-H4-H-S-B

Displacement : 315cc

Flange : SAE"A"4-Bolt

Shaft Size : 1" Parallel

Crosshole : .40 dia

Oil port : 7/8-14 SAE

Contact Now

BMPH-315-H4-H-S-B Motor - SAE"A"4-Bolt, 1" Parallel .40 Dia Crosshole, 7/8-14 SAE

This is a replacement hydraulic motor for Brevini BH series

Main Specifications:
Technical data for BMP with 25 and 1 in and 1 in splined and 28.56 tapered shaft:
Type BMP
BMPH
BMPW
36		 BMP
BMPH
BMPW
50		 BMP
BMPH
BMPW
80		 BMP
BMPH
BMPW
100		 BMP
BMPH
BMPW
125		 BMP
BMPH
BMPW
160		 BMP
BMPH
BMPW
200		 BMP
BMPH
BMPW
250		 BMP
BMPH
BMPW
315		 BMP
BMPH
BMPW
400		 BMP
BMPH
BMPW
500
Geometric displacement (cm3 /rev.) 36 51.7 77.7 96.2 120.2 157.2 194.5 240.3 314.5 389.5 486.5
Max. speed (rpm) cont. 1500 1150 770 615 490 383 310 250 192 155 120
int. 1650 1450 960 770 615 475 385 310 240 190 150
Max. torque (N·m) cont. 55 100 146 182 236 302 360 380 375 360 385
int. 76 128 186 227 290 370 440 460 555 525 560
peak 96 148 218 264 360 434 540 550 650 680 680
Max. output (kW) cont. 8 10 10 11 10 10 10 8.5 7 6 5
int. 11.5 12 12 13 12 12 12 10.5 8.5 7 6
Max. pressure drop (MPa) cont. 12.5 14 14 14 14 14 14 11 9 7 6
int. 16.5 17.5 17.5 17.5 17.5 17.5 17.5 14 14 10.5 9
peak 22.5 22.5 22.5 22.5 22.5 22.5 22.5 18 16 14 12
Max. flow (L/min) cont. 55 60 60 60 60 60 60 60 60 60 60
int. 60 75 75 75 75 75 75 75 75 75 75
Weight (kg) 5.6 5.6 5.7 5.9 6 6.2 6.4 7 6.9 7.4 8

BMPH-315-H4-H-S-B Motor - SAE"A"4-Bolt, 1" Parallel .40 Dia Crosshole, 7/8-14 SAE

BMPH-315-H4-H-S-B Motor - SAE"A"4-Bolt, 1" Parallel .40 Dia Crosshole, 7/8-14 SAE

BMPH-315-H4-H-S-B Motor - SAE"A"4-Bolt, 1" Parallel .40 Dia Crosshole, 7/8-14 SAE

BMPH-315-H4-H-S-B Motor - SAE"A"4-Bolt, 1" Parallel .40 Dia Crosshole, 7/8-14 SAE

BMPH-315-H4-H-S-B Motor - SAE"A"4-Bolt, 1" Parallel .40 Dia Crosshole, 7/8-14 SAE

APPLICATIONS

Agricultural augers, harvesters, seeders, snow plows, railroad maintenance equipment, concrete and asphalt equipment and more.

FEATURES

Designed for medium duty applications, it's use industry-proven spool valve technology, combined with state-of-the-art gerotors. In addition, a wide variety of mounting flanges, shafts, ports and valving options provide design flexibility. Direction of shaft rotation and shaft speed can be controlled easily and smoothly throughout the speed range of the motor, and equipment can be driven direct, eliminating costly mechanical components.

BMPH-315-H4-H-S-B Motor - SAE"A"4-Bolt, 1" Parallel .40 Dia Crosshole, 7/8-14 SAE
