M+S HW470 Hydraulic Orbit Motor Wheel Mounting Flange Hydromotor Dynamic Low Speed High Torque

Name: MS HW470 Hydraulic Orbit Motor Wheel Mounting Flange Hydromotor Dynamic Low Speed High Torque
Brand: HANJIU
Price: 1 USD

Quality M+S HW470 Hydraulic Orbit Motor Wheel Mounting Flange Hydromotor Dynamic Low Speed High Torque wholesale

Brand Name : HANJIU

Model Number : BMER-470

Certification : CE

Place of Origin : CHINA

MOQ : 30 Sets

Price : Negotiable

Payment Terms : L/C, T/T

Supply Ability : 300000 sets per year

Delivery Time : 10-15 work days

Packaging Details : Carton Packing and finally with a Tray, or Wooden Box

Type : hydromotor

Speed : 160rpm1950rpm

Displacement : 470cc

torque : 1085N.M-1180N.M

output : 14.5kw-16.5kw

pressure : 24mpa-27.6mpa

Contact Now

M+S HW470 orbit motor wheel mounting flange hydromotor dynamic low speed high torque hydraulic motor

This type of hydraulic motors are widely used on sweeper machines, sweeper brush,hydraulic scissors lift, platforms

matching brand:

PARKER TORQMOTOR

WHITE TORQMOTOR

ROSS TORQMOTOR
DANFOSS 500/530 MOTORS

1,	model number	BMER-3-475
2,	displacement	475ml/r
3,	flange	wheel Mount
4,	shaft	cone shaft
5,	oil port	G1/2
6,	drain	---
7,	rotation	Standard
8,	paint	Black
9,	replace	Parker TG ,white 500/530

Main Specifications:

Type		BMER 125	BMER 160	BMER 200	BMER 230	BMER 250	BMER 300	BMER 350	BMER 375	BMER 475	BMER 540	BMER 750
Geometric displacement (cm3 /rev.)		118	156	196	228	257	296	345	371	462	540	745
Max. speed (rpm)	cont.	360	375	330	290	290	250	220	200	160	140	100
Max. speed (rpm)	int.	490	470	425	365	350	315	270	240	195	170	120
Max. torque (N*m)	cont.	325	450	530	625	700	810	905	990	1085	980	1050
	int.	380	525	600	710	790	930	1035	1140	1180	1240	1180
	peak	450	590	750	870	980	1120	1285	1360	1260	1380	1370
Max. output (kW)	cont.	12.0	15	15.5	16.0	17.5	18.0	17.5	16.5	14.5	11.5	8.0
Max. output (kW)	int.	14.0	17.5	18.0	19.0	20.0	21.0	20.0	19.0	16.5	15.0	10.0
Max. pressure drop (MPa)	cont.	20.5	20.5	20.5	20.5	20.5	20.5	20.5	20.5	17.5	14	10.5
	int.	24	24	24	24	24	24	24	24	19	17.5	12
	peak	27.6	27.6	27.6	27.6	27.6	27.6	27.6	27.6	20.5	20.5	14
Max. flow (L/min)	cont.	45	60	70	70	75	80	80	75	75	75	75
Max. flow (L/min)	int.	60	75	85	85	90	95	95	90	90	90	90

M+S HW470 Hydraulic Orbit Motor Wheel Mounting Flange Hydromotor Dynamic Low Speed High Torque

HANJIU TECHNOLOGY not only has superb technology and innovative ideas in manufacturing products, but also put a lot of thoughts and efforts in customer communication and after-sales service. After the customer purchases the relevant mechanical devices, HANJIU TECHNOLOGY will pay regular return visits with the customer, give the customer some suggestions for use and help the customer solve the problems that may arise in the use of the product. If a customer encounters a problem with the product during the use of the product, HANJIU TECHNOLOGY will also have professional technical personnel to communicate with the customer and conduct regular inspections and maintenance.

No matter when and where, HANJIU TECHNOLOGY can always provide you with higher quality hydraulic rail motors, how can you miss it?
