Danfoss OMT 315 Hydraulic Orbit Motor 4 Bolts Tapered Shaft BSP Port Threads

Name: Danfoss OMT 315 Hydraulic Orbit Motor 4 Bolts Tapered Shaft BSP Port Threads
Brand: HANJIU
Price: 1 USD

Quality Danfoss OMT 315 Hydraulic Orbit Motor 4 Bolts Tapered Shaft BSP Port Threads wholesale

Brand Name : HANJIU

Model Number : BMT315

Certification : ISO9001:2015

Place of Origin : China

MOQ : 20 Sets

Price : Negotiable

Payment Terms : L/C, T/T, Western Union, Paypal

Supply Ability : 100,000 Sets per year

Packaging Details : Carton Packing, and finally with pallet or wooden box

Categories : Hydraulic Wheel Motor

Name : OMT315/MT315

Max.output : cont.31.2kw/int.35kw

max torque : cont.1080N.m/int.1260N.m

Flange : φ200mm wheel motors

Shaft : Cone shaft 1:10

Contact Now

Danfoss OMT 315 Motor 4 Bolts Hydraulic orbit motor tapered shaft BSP Port threads

Output volume (cc/rev): 326.3
Shaft: cone shaft 1.5 inch
max r.p.m.: 380
Torque max. (Nm): 950/1140
Power max. (kW): 30
Pressure difference (bar): 180
Inlet pressure (bar): 280
Volume flow max. (l/min): 125
Engine version: with non-return valves
Connection: G 3/4"
Leakage oil connection: G 1/4"

Main Specifications:

Type		BMT 160	BMT 200	BMT 230	BMT 250	BMT 315	BMT 400	BMT 500	BMT 630	BMT 800
displacement (cm3/rev. )		161.1	201.4	232.5	251.8	326.3	410.9	523.6	629.1	801.8
Max. speed (rpm)	cont.	625	625	536	500	380	305	240	196	154
Max. speed (rpm)	int.	780	750	643	600	460	365	285	233	185
Max. torque (N.m)	cont.	470	590	670	730	950	1080	1220	1318	1464
	int.	560	710	821	880	1140	1260	1370	1498	1520
	peak	669	838	958	1036	1346.3	1450.3	1643.8	1618.8	1665
Max. output (KW)	cont.	27.7	34.9	34.7	34.5	34.9	31.2	28.8	25.3	22.2
Max. output (KW)	int.	32	40	40	40	40	35	35	27.5	26.8
Max.pressure drop (MPa)	cont.	20	20	20	20	20	18	16	14	12.5
	int.	24	24	24	24	24	21	18	16	13
	peak	28	28	28	28	28	24	21	19	16
Max. flow (L/min)	rated	80	100	100	100	100	100	100	100	100
	cont.	100	125	125	125	125	125	125	125	125
	int.	125	150	150	150	150	150	150	150	150
Max. inlet pressure (Mpa)	cont.	21	21	21	21	21	21	21	21	21
	int.	25	25	25	25	25	25	25	25	25
	peak	30	30	30	30	30	30	30	30	30
Weight (kg)		19.5	20	20.4	20.5	21	22	23	24	25

Danfoss OMT 315 Hydraulic Orbit Motor 4 Bolts Tapered Shaft BSP Port Threads

other types we supply same as Danfoss

151B3009 OMT 315

151B3010 OMT 400

151B3011 OMT 500

151B3012 OMT 160

151B3013 OMT 200

151B3014 OMT 250

151B3015 OMT 315

151B3016 OMT 400

151B3017 OMT 500

151B3018 OMT 160

151B3019 OMT 200

151B3020 OMT 250

151B3021 OMT 315

151B3022 OMT 400

151B3023 OMT 500

151B3042 OMT 160

151B3043 OMT 200

151B3044 OMT 250

151B3045 OMT 315

151B3056 OMT 250

151B3057 OMT 400

151B3062 OMT 500
