Engine Omr160 ø25 Shaft Orbit Hydraulic Motor Rear Ports Compatible Danfoss 151-6194

Shijiazhuang Hanjiu Technology Co.,Ltd
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

Engine Omr160 ø25 Shaft Orbit Hydraulic Motor Rear Ports Compatible Danfoss 151-6194

Brand Name : HANJIU

Model Number : OMR160

Certification : CE

Place of Origin : China

MOQ : 100 Pieces

Price : Start from us$60

Payment Terms : L/C, D/A, D/P, T/T, Western Union

Supply Ability : 10000 pieces per year

Delivery Time : 55 work days

Packaging Details : Standard export package

Item : Orbital Motor

Model number : OMR160

Manufacturer : Hanjiu

Feature : with rear port

Contact Now

Engine OMR160, Ø25 shaft, rear ports, compatible with Danfoss 151-6194

Quick review:

This is an OMR Orbital Motor with rear port. It is form, fit and function compatible with Danfoss OMR 151-6194. Dealers and users of Danfoss sell and use it directly as an OMR 151-6194 compatible motor.

Technical information
Cylindrical shaft Ø25 mm Flange Sae
A 2 bolt - centring 82.5 mm Rear ports
ref Danfoss 151-6194

Parameters:

Type BMR
BMRS
36
BMR
BMRS
50
BMR
BMRS
80
BMR
BMRS
100
BMR
BMRS
125
BMR
BMRS
160
BMR
BMRS
200
BMR
BMRS
250
BMR
BMRS
315
BMR
BMRS
375
Geometric displacement (cm3 /rev.) 36 51.7 81.5 102 127.2 157.2 194.5 253.3 317.5 381.4
Max. speed (rpm) cont. 1085 960 750 600 475 378 310 240 190 155
int. 1220 1150 940 750 600 475 385 300 240 190
Max. torque (N·m) cont. 72 100 195 240 300 360 360 390 390 365
int. 83 126 220 280 340 430 440 490 535 495
peak 105 165 270 320 370 460 560 640 650 680
Max. output (kW) cont. 8.5 9.5 12.5 13 12.5 12.5 10 7 6 5
int. 9.8 11.2 15 15 14.5 14 13 9.5 9 8
Max. pressure drop (MPa) cont. 14 14 17.5 17.5 17.5 16.5 13 11 9 7
int. 16.5 17.5 20 20 20 20 17.5 15 13 10
peak 22.5 22.5 22.5 22.5 22.5 22.5 22.5 20 17.5 15
Max. flow (L/min) cont. 40 50 60 60 60 60 60 60 60 60
int. 45 60 75 75 75 75 75 75 75 75
Weight (kg) 6.5 6.7 6.9 7 7.3 7.6 8 8.5 9 9.5

Below models also available:

151-6210
151-6211
151-6212
151-6213
151-6214
151-6215
151-6216
151-6217

About manufacturer:

Hanjiu is a hydraulic orbital motor manufacturer from China. Currently a strong contender in Europe for Danfoss, White, M+S, Brevini. In North America, Latin America and Australia are strong contenders for Eaton, Parker. You can get high-end motors in Hanjiu that are compatible with Danfoss, M+S, White, Dana Brevini, Eaton, Parker in form, fit and function, with a complete range, more reasonable prices, stable and fast delivery.

Contact us to discuss your needs, tell us your needs, and we will assist you in solving your difficulties and achieving a reliable and competitive supply.
