Name: CE High Torqmotor CROSS Hydraulic Motor 500300A3123ZAAAA 4 Hole Front Ports
Brand: HANJIU
Price: 1 USD

Brand Name : HANJIU

Model Number : BMER-2-300

Certification : CE

Place of Origin : China

MOQ : 100 Pieces

Price : Contact the seller to get a quote

Payment Terms : L/C, D/A, D/P, T/T, Western Union

Supply Ability : 10000 pieces per year

Delivery Time : 55 work days

Packaging Details : Box, Pallet

Item : Torqmotor

OEM # : 500300A3123ZAAAA

Manufacturer : Hanjiu

Displacement : 300 ml/r

Mounting flange : 7/8-14 SAE

Shaft type : 14 Teeth shaft

Contact Now

High Torqmotor CROSS Hydraulic Motor 500300A3123ZAAAA 4-Hole Front Ports 7/8" O-ring (S)

HANJIU supply the LSHT Torqmotors BMER Series motors matching white/danfoss/cross series motors, the same function,

same specification, 100% interchangeable.

Details specifications

Series:	RE500/501
Shaft:	14 Tooth Spline
Rotation:	Reverse Timed Manifold
Displacement (cm3/rev):	0300
Mounting:	4-Hole Front Aligned Ports 7/8” O-Ring
Geometric Displacement:	300cm3/rev (18.3 in3/rev)
Maximum Speed:	320 rev/min
Maximum Oil Flow (continuous / intermittent):	76 lpm (20 gpm) / 95 lpm (25 gpm)
Max. Differential Pressure (continuous / intermittent):	207 bar (3000 PSID) / 276 bar (4000 PSID)
Maximum Supply Pressure:	300 bar (4350 PSIG)
Maximum Torque - Continuous / Intermittent:	7300 lb-in / 8300 lb-in
Maximum Performance:	33 KW (45HP)

Type		BMER-2 125	BMER-2 160	BMER-2 200	BMER-2 230	BMER-2 250	BMER-2 300	BMER-2 350	BMER-2 375	BMER-2 475	BMER-2 540	BMER-2 750
Geometric displacement (cm3 /rev.)		118	156	196	228	257	296	345	371	462	540	745
Max. speed (rpm)	cont.	360	375	330	290	290	250	220	200	160	140	100
Max. speed (rpm)	int.	490	470	425	365	350	315	270	240	195	170	120
Max. torque (N*m)	cont.	325	450	530	625	700	810	905	990	1085	980	1050
	int.	380	525	600	710	790	930	1035	1140	1180	1240	1180
	peak	450	590	750	870	980	1120	1285	1360	1260	1380	1370
Max. output (kW)	cont.	12.0	15	15.5	16.0	17.5	18.0	17.5	16.5	14.5	11.5	8.0
Max. output (kW)	int.	14.0	17.5	18.0	19.0	20.0	21.0	20.0	19.0	16.5	15.0	10.0
Max. pressure drop (MPa)	cont.	20.5	20.5	20.5	20.5	20.5	20.5	20.5	20.5	17.5	14	10.5
	int.	24	24	24	24	24	24	24	24	19	17.5	12
	peak	27.6	27.6	27.6	27.6	27.6	27.6	27.6	27.6	20.5	20.5	14
Max. flow (L/min)	cont.	45	60	70	70	75	80	80	75	75	75	75
Max. flow (L/min)	int.	60	75	85	85	90	95	95	90	90	90	90
